SFH690BT

OPTOISOLATOR 3.75KV TRANS 4-SOP

1 review(s) | Add your review

Availability: In stock

Manufacturer: Vishay Semiconductor Opto Division

SKU: SFH690BT

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

SFH690BT Description

marking code	Part No.	Manufacturer	Package	Pin	Memo
690B	SFH690BT		SOP-4	0	Optocoupler Phototransistor Output

Operating Temperature	-55°C ~ 100°C
Rise / Fall Time (Typ)	3μs, 4μs
Mounting Type	Surface Mount
Supplier Device Package	4-SOP (2.54mm)
Current Transfer Ratio (Max)	300% @ 5mA
Vce Saturation (Max)	300mV
Number of Channels	1
Voltage - Output (Max)	70V
Turn On / Turn Off Time (Typ)	5μs, 3μs
Package	Tape & Reel (TR),Cut Tape (CT),Digi-Reel?
Current Transfer Ratio (Min)	100% @ 5mA
Voltage - Forward (Vf) (Typ)	1.15V
Current - Output / Channel	50mA
Input Type	DC
Current - DC Forward (If) (Max)	50 mA
Voltage - Isolation	3750Vrms
RoHS	RoHS
Output Type	Transistor
