AK3102

IC CORELESS CURRENT SENSE 14SOP

1 review(s) | Add your review

Availability: In stock

Manufacturer: Asahi Kasei Microdevices/AKM

SKU: AK3102

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

AK3102 Description

Voltage - Supply	4.5V ~ 5.5V
Sensitivity	100mV/A
Linearity	±0.6%
Mounting Type	Surface Mount
For Measuring	AC/DC
Supplier Device Package	24-SMD
Current - Supply (Max)	20mA
Number of Channels	1
Output	Ratiometric, Voltage
Package	Tape & Reel (TR),Cut Tape (CT),Digi-Reel?
Current - Sensing	21A
Response Time	2μs
Polarization	Unidirectional
Frequency	210kHz
Sensor Type	Hall Effect, Open Loop
Operating Temperature	-40°C ~ 90°C (TA)
Accuracy	±1.5%
RoHS	RoHS
