ADG1209YCPZ-REEL7

IC MULTIPLEXER DUAL 4X1 16LFCSP

1 review(s) | Add your review

Availability: In stock

Manufacturer: Analog Devices Inc.

SKU: ADG1209YCPZ-REEL7

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

ADG1209YCPZ-REEL7 Description

Operating Temperature	-40°C ~ 125°C (TA)
Channel Capacitance (CS(off), CD(off))	1.5pF, 4.5pF
On-State Resistance (Max)	200Ohm
Mounting Type	Surface Mount
Supplier Device Package	16-LFCSP-VQ (4x4)
Switch Circuit	SP4T
Voltage - Supply, Dual (V±)	±5V ~ 16.5V
Number of Circuits	2
Package	Tape & Reel (TR),Cut Tape (CT),Digi-Reel?
Charge Injection	0.4pC
Switch Time (Ton, Toff) (Max)	95ns, 100ns
Voltage - Supply, Single (V+)	5V ~ 16.5V
Crosstalk	-85dB @ 1MHz
Multiplexer/Demultiplexer Circuit	4:1
Channel-to-Channel Matching (ΔRon)	3.5Ohm
-3db Bandwidth	550MHz
RoHS	RoHS
Current - Leakage (IS(off)) (Max)	100pA
