PMP4501G135

SMALL SIGNAL BIPOLAR TRANSISTOR

1 review(s) | Add your review

Availability: In stock

Manufacturer: Rochester Electronics, LLC

SKU: PMP4501G135

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

PMP4501G135 Description

Operating Temperature	150°C (TJ)
Vce Saturation (Max) @ Ib, Ic	400mV @ 5mA, 100mA
Mounting Type	Surface Mount
Current - Collector (Ic) (Max)	100mA
Supplier Device Package	5-TSSOP
Current - Collector Cutoff (Max)	15nA (ICBO)
Voltage - Collector Emitter Breakdown (Max)	45V
Power - Max	300mW
Package	Bulk
DC Current Gain (hFE) (Min) @ Ic, Vce	200 @ 2mA, 5V
Frequency - Transition	250MHz
RoHS	RoHS
Transistor Type	2 NPN (Dual) Matched Pair, Common Emitter
