164J36

PWR XFMR LAMINATED 36VA TH

1 review(s) | Add your review

Availability: In stock

Manufacturer: Hammond Manufacturing

SKU: 164J36

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

164J36 Description

Current - Output (Max)	Parallel 2A, Series 1A
Termination Style	PC Pin
Mounting Type	Through Hole
Primary Winding(s)	Single
Secondary Winding(s)	Dual
Size / Dimension	66.68mm L x 55.55mm W
Power - Max	36VA
Package	Bulk
Weight	1.1 lbs (499 g)
Voltage - Primary	115V
Type	Laminated Core
Voltage - Secondary (Full Load)	Parallel 18V, Series 36V
Height - Seated (Max)	39.70mm
Voltage - Isolation	2500Vrms
RoHS	RoHS
Center Tap	No
