LM5009ASD

SWITCHING REG, 0.36A

1 review(s) | Add your review

Availability: In stock

Manufacturer: Rochester Electronics, LLC

SKU: LM5009ASD

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

LM5009ASD Description

marking code	Part No.	Manufacturer	Package	Pin	Memo
5009ASD	LM5009ASD		SDC08B	8	100V, 150 mA Constant On-Time Buck Switching Regulator

Operating Temperature	-40°C ~ 125°C (TJ)
Frequency - Switching	50kHz ~ 1.1MHz
Voltage - Output (Min/Fixed)	2.5V
Mounting Type	Surface Mount
Current - Output	150mA
Supplier Device Package	8-WSON (4x4)
Synchronous Rectifier	No
Function	Step-Down
Output Configuration	Positive
Voltage - Input (Min)	6V
Package	Bulk
Topology	Buck
Voltage - Input (Max)	95V
Number of Outputs	1
RoHS	RoHS
Voltage - Output (Max)	95V
Output Type	Adjustable
