IRGB4615DPBF-6367366

IGBT WITH RECOVERY DIODE

1 review(s) | Add your review

Availability: In stock

Manufacturer: Rochester Electronics, LLC

SKU: IRGB4615DPBF-6367366

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

IRGB4615DPBF-6367366 Description

Operating Temperature	-40°C ~ 175°C (TJ)
Mounting Type	Through Hole
Current - Collector (Ic) (Max)	23 A
Supplier Device Package	TO-220AB
Gate Charge	19 nC
Voltage - Collector Emitter Breakdown (Max)	600 V
Power - Max	99 W
IGBT Type	-
Package	Tube
Current - Collector Pulsed (Icm)	24 A
Td (on/off) @ 25°C	30ns/95ns
Vce(on) (Max) @ Vge, Ic	1.85V @ 15V, 8A
Test Condition	400V, 8A, 47Ohm, 15V
Input Type	Standard
Reverse Recovery Time (trr)	60 ns
Switching Energy	70μJ (on), 145μJ (off)
RoHS	RoHS
